Multifunction digital rotary viscometers - SAVISC155
Digital Rotary Viscometers are instruments for testing fluid viscosity and resistance. This gauges have constantly control rotate speed system, and are widely applied in the field of petrol chemistry, medicine, food, industry, laboratory, scientific research, and others.
The display shows directly the viscosity, rotating speed, rotor number and the maximum measured viscosity for the selected rotor for the current rotating speed.
The combination of the different selected speeds (adjustable variable speed) and the spindles set provide operating flexibility, complying with numerous requirements of product analysis and industrial quality control standards.
|
Modello Model |
SAVISC155-1 |
SAVISC155-2 |
SAVISC155-3 |
|
Standard |
ISO 2555 ; ASTM D 1084-B ; ASTM D 2196 ; AS/NZS 1580.214.5 |
||
|
Campo di misura Measuring range |
10 ~ 600.000 mPa·s (cP) |
10 ~ 6.000.000 mPa·s (cP) |
100 ~ 80.000.000 mPa·s (cP) |
|
Precisione / Accuracy |
± 1,0% of range |
||
|
Ripetibilità Repeatability |
± 0,5% |
||
|
Velocità rotazionale Rotate speed |
1 ~ 60 r/min |
0,1 ~ 100 r/min |
0,1 ~ 100 r/min |
|
Rotori / Rotors |
1, 2, 3, 4 (4 pcs) |
||
|
Riscaldatore Heating device |
-- |
||
|
Sonda di temperatura Temperature probe |
Optional |
||
|
Campo temperatura Temperature range |
-20 ~ +120 °C |
||
|
Precisione temperatura Temperature accuracy |
0,1 °C |
||
|
Uscita dati Data output |
√ |
||
|
Alimentazione Power supply |
220 Vac |
||
|
Dimensioni Dimensions |
400 x 360 x 380 mm |
||
|
Peso / Weight |
10 Kg |
||
Dotazione Standard / Standard Supply:
Unità centrale / Main unit
Rotori (4pz) / Rotors (4pcs)
Manuale d’uso / User’s manual
Accessori Opzionali / Optional Accessories:
Software di analisi / PC Advanced analysis software
Stampante / Printer
Rotore basse viscosità (rotore n.0) / Low viscosity adapter (no.0 rotor)
Rotore piccole quantità campione (rotori n.21/27/28/29 inclusi)* / Small sample adapter (no.21/27/28/29 rotors included)*
Sonda di temperatura (-20 ~ 120°C) / Temperature probe (-20 ~ 120 °C)
Olio campione / Standard oil
Certificato di taratura / Calibration report
(*) Specificare prima dell’ordine / Must be specified before the order.
Campo di misura con rotore per piccole quantità campione / Measuring range with small sample adapter:
SAVISC155-1 : 10 ~ 100.000 mPa·s (cP)
SAVISC155-2 : 10 ~ 1.000.000 mPa·s (cP)
SAVISC155-3 : 50 ~ 10.000.000 mPa·s (cP)
