Digital rotary viscometers - SAVISC152
Digital Rotary Viscometers are instruments for testing fluid viscosity and resistance. This devices have a constantly control rotate speed system, and are widely applied in the field of petrol chemistry, medicine, food, industry, laboratory, scientific research, and many others.
|
Modello / Model |
SAVISC152-1 |
SAVISC152-2 |
|
Standard |
ISO 2555 ; ASTM D 1084-B ; ASTM D 2196 ; AS/NZS 1580.214.5 |
|
|
Campo di misura Measuring range |
10 ~ 100.000 mPa·s (cP) |
10 ~ 2.000.000 mPa·s (cP) |
|
Precisione / Accuracy |
± 1% of range |
|
|
Ripetibilità / Repeatability |
0,5 |
|
|
Velocità rotazionale Rotate speed |
6 / 12 / 30 / 60 r/min |
0,3 / 0,6 / 1,5 / 3 / 6 / 12 / 30 / 60 r/min |
|
Rotori / Rotors |
no. 1, 2, 3, 4 (4 pcs) |
|
|
Parametri visualizzati Displayed parameters |
Rotation speed ; Rotors type ; Results ; Temperature (optional) |
|
|
Alimentazione Power supply |
220 Vac |
|
|
DImensioni / Dimensions |
308 x 300 x 450 mm |
|
|
Peso / Weight |
10 Kg |
|
Dotazione Standard / Standard Supply:
Unità centrale / Main unit
Rotori (4pz) / Rotors (4pcs)
Manuale d’uso / User’s manual
Accessori Opzionali / Optional Accessories:
Stampante / Printer
Rotore basse viscosità (rotore n.0) / Low viscosity adapter (no.0 rotor)
Olio campione / Standard oil
Certificato di taratura / Calibration report
