Colour difference meters - SA130
Color meter is a non destructive testing device used to check cromatic differences between 2 or more samples according to Lab and Lch colour coordinates. Color meters are able to operate on plastic, metal, printings and painted surfaces and are mainly employed to perform quality checks on incoming and outgoing goods. The small size makes it a perfect device to be used for field measurement.
|
Modello / Model |
SA130 |
|
Standard |
ISO 11664-1 ; ISO 11664-2 ; ISO 11664-3 ; ISO 11664-4 ; ISO 11664-5 ; ISO 2469 ; ASTM C 609 ; ASTM D 2244 ; ASTM E 308 |
|
Illuminante / Illuminating |
8°/d (8 degree viewing angle, diffused illumination) |
|
Sensore / Detector |
Silicon photoelectric diode |
|
Filtro riflessione speculare Specular reflection filter |
SCI (including specular reflection) |
|
Posizionamento / Location |
Illuminating location and cross locating |
|
Precisione / Accuracy |
≤ 0,80 ΔE*ab |
|
Ripetibilità / Repeatability |
≤ ΔE*ab 0,08 (average of 30 measurements of standard white plate) |
|
Apertura di misurazione / Measuring aperture |
Ø 4 mm |
|
Valori cromatici / Color space |
CIE L*a*b*C*h* ; CIE L*a*b* ; CIE XYZ |
|
Valori differenziali / Color difference formula |
ΔE*ab ; ΔL*a*b* ; ΔE*C*h* |
|
Sorgente luminosa / Light source |
D65 |
|
Tipo di sorgente luminosa / Light source device |
LED blue light excitation |
|
Calibrazione / Calibration |
White and black calibration |
|
Uscita dati / Data output |
√ |
|
Memoria / Memory |
100 standard ; 20.000 samples |
|
Durata lampada / Lamp life |
More than 1,6 million samples |
|
Alimentazione / Power supply |
Rechargeable battery |
|
Dimensioni / Dimensions |
205 x 67 x 80 mm |
|
Peso / Weight |
450 g |
Dotazione Standard / Standard Supply:
Unità centrale / Main unit
Piastra di calibrazione / Calibration plate
Cavo e software / Cable and software
Valigetta / Carrying case
Manuale d’uso / User’s manual
Accessori Opzionali / Optional Accessories:
Stampante / Printer
Accessorio per la misura delle polveri / Test box for powder
Certificato di taratura / Calibration report
