Bench hardness testers - SAB150-B and SAB150-BM



Devices employed to evaluate hardness through indentation tests run by applying a fixed load for a known time on a penetrator in contact with the sample.

The shape, the size, the material and the mass of the penetrator determine the hardness scale read by the instrument.

Bench hardness testers are recommended for metrological laboratories and every application which demands maximum accuracy and repeatability.



Standard delivery:

  • Diamond cone penetrators
  • Penetrators with steel ball 1/16”
  • Replacement balls
  • Large flat table Ø 150mm
  • Small flat table Ø 55mm
  • V shaped table
  • Test blocks supplied HRC,HRB



Complying with standards: UNI-DIN-ASTM

Model

SAB150-B

SAB150-BM

Activation

Manual

Motorized

Measuring load Rockwell A, B, C

60/100/150 Kgf

Accuracy

±1.5HRC

Max height  test

170 mm

Depth

165 mm

Weight

100 Kg

Standard supply

Diamond cone indenter

1/16”  indenter with steel ball

Large flat table Ø 150mm

Small flat table Ø 55mm

V shaped table

Test blocks supplied HRC,HRB

Optional accessories

Certificate
