Automatic scribe marks machine for corrosion testing - SASMM539
In order to carry out salt spray corrosion tests, the sample must have specific incisions made, as indicated by the standard. Marking by hand, may not always be uniform and repeatable on every sample and may influence the test and lead to varying results and evaluations. Also, when it’s necessary to prepare several specimens, working on the piece manually, can be time consuming and expensive. Using an automatic device allows for uniform tracing and helps save time and money. Thanks to its rotating tip, the markings will be flawless along the borders
Modello / Model |
SASMM539 |
Corsa Stroke |
0 ~ 150 mm |
Profondità d’incisione |
0 ~ 2000 µm |
Larghezza incisione Marking width |
2 mm |
Spessore campione Test panel thickness |
0 ~ 5 mm (including the coating thickness) |
Piano magnetico Magnetic plate |
√ |
Punta rotante Rotary tip |
√ |
Dimensione piano di lavoro Working plate size |
250 x 125 mm |
Dimensioni Dimensions |
374 x 320 x 410 mm |
