Articulating professional video inspection systems - SAVJ
Video inspection systems allow to visually reach areas otherwise not accessible to operators, like internal parts of cylinders, pipes, tanks, machine parts and so on. The small size and the outstanding battery life make them the ideal devices to be used in every industrial field.
The adjustable head allows to inspect less accessible parts and with bends.
Modello / Model |
SAVJ6150 |
SAVJ6300 |
SAVJ4150 |
SAVJ4300 |
Sensore / Sensor |
CMOS |
|||
Schermo / Display |
3,5” LCD |
|||
Risoluzione display / Display resolution |
320 x 240 |
|||
Pixels telecamera / Camera pixels |
350.000 |
|||
Campo visivo / Field of view |
> 90° |
> 120° |
||
Profondità di campo nitido / Depth of field |
15 mm ~ ∞ |
8 ~ 80 mm |
||
FN0 |
2,8 ; 4,9 |
|||
Illuminamento / Brightness |
LED high lux |
|||
Controllo luminosità / Brightness control |
Adjustable |
|||
Diametro sonda / Probe diameter |
6,4 mm |
4,5 mm |
||
Lunghezza testa sonda / Probe head length |
18 mm |
15 mm |
||
Materiale testa sonda / Probe head material |
Stainless steel |
|||
Articolazione / Articulating |
360° |
|||
Grado di impermiabilità / Waterproofness grade |
IP65 |
|||
Materiale cavo sonda / Line material |
Stainless steel wire |
|||
Lunghezza sonda / Probe length |
1,5 mt |
3 mt |
1,5 mt |
3 mt |
Formato immagine / Picture format |
JPG ; 800 × 600 pixel |
|||
Formato video / Video format |
AVI ; 640 × 840 pixel |
|||
Frequenza fotogrammi / Frame rate |
15 ~ 30 fps |
|||
Memoria / Memory |
External SD card |
|||
Uscita dati / Data output |
Mini-USB |
|||
Uscita video / Video output |
NTSC/PAL |
|||
Alimentazione / Power supply |
Rechargeable battery |
|||
Tempo di ricarica / Charge time |
4h |
|||
Autonomia / Working time |
> 2h |
|||
Tensione di alimentazione esterna Exterior supply voltage |
220 Vac |
|||
Peso / Weight |
590 g |
Dotazione Standard / Standard Supply:
Unità centrale / Main unit
Sonda / Probe
Micro SD / Micro SD
Valigetta / Carrying case
Manuale d’uso / User’s manual
